RTS Transmission Case Kit, SuperMax 400, TH400 Aluminium Transmission Case & SB Chrysler / Mopar, Bellhousing, Kit

RTS SuperMax TH400 Transmission Case with SB Chrysler Bellhousing Kit

RTS SuperMax TH400 Transmission Case

RTS now offers aftermarket TH400 and Powerglide aluminium transmission cases! They are constructed from A356-T6 heat treated aluminium through a permanent mould process which increases strength and ductility over the OEM designs. These are intended to be used in street/strip or high horsepower drag race applications.

Features include:

• Speedometer and governor provisions
• Longer band anchor pins captured by oversize bosses
• Multiple external pressure taps allow for monitoring of circuit pressures
• Accepts all style oil pumps, including 8-bolt and vari-pitch designs
• Heli-coiled bellhousing and oil pump threads
• Accepts Reid aftermarket bellhousings
• Accepts oem kickdown switch
• Pre-machined to fit larger custom planetary gear carriers
